Quick Spa is an international leader in the production of nautical equipment, headquartered in Ravenna, Italy. The company designs, manufactures, and engineers all its products in its own facilities in Italy and distributes them worldwide in over 110 countries. With more than 450 employees and a production area of 40,000 m², Quick Spa offers a comprehensive range of high-quality products for yachts and superyachts.

Vertical anchor winch QUICK PRINCE DP2E

Robust, vertical, electric windlass with powerful watertight motor (protection class IP67).Base, chain cover and, if necessary, mooring cap in stainless steel AISI316. Combination chain sprocket made of chrome-plated bronze, for hoisting chain DIN 766 and beaten anchor line (12-14 mm). Suitable for boats from eight to ten metres in length.Manual free fall. Low-wear operation, simple installation and long service life thanks to vertical motor without angular gear: the patented, highly effective planetary gear enables powerful work with low power consumption, low weight and high efficiency. Flat design. Suitable for deck thickness 20-40 mm.Powerful motor 12 V / 800 W, current consumption 84 A.Working load in operation 95 kg, maximum 290 kg. Maximum pulling force 820 kg.Maximum hauling speed with 8 mm chain 22.5 m/min, under load 15.2 m/min.Available with and without hauling capstan.Scope of delivery: winch, relay box, built-in sensor for chain counter, plastic crank, base seal, drilling template.Switches and other accessories can be found under "Accessories" (see below).Other sizes and other QUICK windlass models are also available on request.

From €1,295.01 *

Details

QUICK PRINCE windlass accessories

Accessories for the QUICK PRINCE windlasses.Foot switch for lowering and retrieving the anchor.Wired remote control with non-slip housing. The flexible cable has a length of up to 4 meters. The plug and socket are waterproof to IP67.Power supply: 10 - 30 V DCCurrent consumption in operation: 15 mA (12 V)Operating temperature: -10 - 60 °CProtection class: IP67Dimensions: 154 x 59 x 38 mmWeight: 120 g

From €24.95 *

Details

Vertical anchor winch QUICK PRINCE DP2

Robust electric windlass with powerful watertight motor (protection class IP67).Base, chain cover and, if necessary, mooring capstan made of stainless steel AISI316. Combination chain sprocket made of chromed bronze, for hoisting chain DIN 766 and beaten anchor line (12-14 mm). Suitable for boats from seven to twelve metres in length.Manual free fall. Low-wear operation, easy installation and long service life. Flat design. Suitable for deck thickness 25-50 mm.Powerful motor 12 V / 700 W, current consumption 95 A. Working load in operation 100 kg, maximum 300 kg. Maximum pulling force 680 kg. Maximum hauling speed with 8 mm chain 22.6 m/min, under load 11.6 m/min. Available with and without hauling capstan.Scope of delivery: winch, relay box, built-in sensor for chain counter, plastic crank, base seal, drilling template.Switches and other accessories can be found under "Accessories & Spare Parts" (see below).Other sizes and other QUICK windlass models are also available on request.

From €1,250.00 *

Details
