The DHR150-series searchlight is a Classic. Introduced in the 60's it has been a popular fixture in the recreational boating ever since. Thanks to the evolvement of LED technology, DHR decided to transition to modern LED technology for this searchlight. The body of the spot is made from stainless steel - type CB with below deck control lever and a through deck and cable duct made from chrome plated brass, allowing a turning range of 360° horizontal, 30° vertical.protection class IP66. Additionally, DHR selected a unique optical design to realize a clear focused spot, while keeping stray light to a minimum. The LED unit (see matching article) can also be used to retrofit older headlights.
Powerful searchlight with electric remote control.The housing is made of chrome-plated brass, the base is made of stainless steel.The drive unit is integrated into the lamp housing and has two speeds. The swivelling range is 70° vertically and 360° horizontally.Supplied complete with control unit, sealed-beam light source and 3 metre connection cable. Light intensity: 500,000 cd (8''), 230,000 cd (7'')Weight: 5 kg (8''), 4.1 kg (7'')The replacement bulb for the 8'' searchlight is available under item number 3311-812.Also available as accessories on request: extension cable, control unit for a second control station, bulb for the 7'' searchlight.
A searchlight for mounting on the wheelhouse. Searchlight proven for many years in maritime, inland and sports navigation. Searchlight type 210 with internal control, for mounting on the wheelhouse (max. deck thickness 35 mm). Heavy professional design of the Dutch manufacturer Den Haan (DHR). Housing and fittings made of white powder coated seawater resistant aluminum. The use of fully encapsulated watertight high-intensity GE sealed beam inserts reliably prevents corrosion or tarnishing of the reflector. The below-deck control unit with deck and cable feed-through is made of chrome-plated brass. It allows 30° vertical adjustment and 360° horizontal adjustment of the spotlight. Supplied with original GE sealed beam light inserts. Range: 10Lux in the target area. Swivelling range: horizontally 360°, vertically 13°.Protection class: IP56.Specifications of range: at 1 lux in the target range.
The following accessories are available for the large DHR type 260 marine halogen searchlights.The lower deck control unit allows the searchlight to be swivelled vertically by up to 65° and rotated by 360°. The stainless steel support rod is available in two different lengths.With the extension standpipe, the position of the floodlight can be raised by 800 mm above deck.
Bright LED searchlight made of seawater-resistant die-cast aluminium.Can be rotated horizontally by 360°. Inclination angle down to 17° and up to 9°. Can be used with 12 and 24 volt on-board power supply. Low power consumption with a bulb life of approx. 40,000 hours. Unlike halogen headlamps, there are no problems with loosening of the lamps in case of vibrations.The control panel (CPF-53) is included in the delivery. Dimensions (W x H x D) Spotlight: 232 x 199 x 206 mm. Control panel: 130 x 100 x 80 mm. Cut-out dimensions for control panel: 112 x 67 mm. Cable length: 4.80 m. Weight: 4.2 kg.A wireless remote control or another control panel for a second control stand are available as accessories. There is also an LED conversion kit for the halogen version (HR-1012) of the searchlight. Please enquire.
The DHR150-series searchlight is a Classic. Introduced in the 60's it has been a popular fixture in the recreational boating ever since. Thanks to the evolvement of LED technology, DHR decided to develop a drop-in PAR46 LED replacement for the 150-series. No special modifications are needed for installation. The existing wiring can be connected to the LED-insert - without the need for extra tooling. Compared to the 100-250 Watt incandescent equivalent, it boosts a luminous intensity of 200.000 Candela (measured) using only 10 W of energy. A performance guaranteed over a voltage range of 10 - 32 VDC. Additionally, DHR selected a unique optical design to realize a clear focused spot, while keeping stray light to a minimum. An extreme narrow bundle makes the 150 LED-replacement the best performing compact marine searchlights of its class. Direct replacement the following GE Sealed beam lamps: PAR46 Sealed beam GE4537-2 PAR46 Sealed beam GE4553
A compact spot light with integrated high performance LEDs for an intensive light and consistent illumination, with 6.500 Kelvin close to daylight. The coated aluminium body is corrosion resistant, dust and water-proof.Integrated electronics provide for an effective reverse voltage protection and guarantee a continual brightness even with a fluctuating operating voltage of 9 to 33 Volt. In addition temperature sensors protect the working light spot from overheating..Available in two power classes: 800 Lumen at 13 W and 2100 Lumen at 21 W and two colour versions of the case: black and white. Shipping including a 1 m marine cable and a mounting bracket from stainless steel.
Powerful LED searchlight 230CS from DEN HAAN ROTTERDAM. Due to its compact design, the searchlight is ideal for tugs, workboats and inland vessels.The headlamp housing is made of seawater-resistant aluminium with a white powder coating. Inside there is a high-quality parabolic reflector that ensures optimum light diffusion. The colour temperature is 5000 K. The floodlight is waterproof according to protection class IP66. Its luminous intensity is comparable to that of a 1000 Watt halogen searchlight.The optional "below deck control unit" allows vertical swivelling up to 65° and 360° rotation of the spotlight.
LED conversion kit for the SANSHIN halogen searchlight HR-1012U. With this conversion kit, the halogen searchlight of the RCL-100 series (whether in the 12-volt or 24-volt version) can be converted into the modern LED searchlight HRL-2070U (Article-No. 3316-001).Unlike halogen headlamps, there are no problems with the LED insert loosening the lamps in case of vibrations. The bulbs have a service life of approx. 40,000 hours with low power consumption.If the halogen searchlight HR-1012U is more than 20 years old or has been used very intensively for several years, the exchange kit including the motor (Article-No. 3316-142) is a good choice. Replacing the motor - for the vertical control of the searchlight - is quicker and easier in the complete conversion kit than individually. Especially as the searchlight is already screwed on for conversion to LED bulbs anyway.How to insert the LED conversion kit into the searchlight is described in the "Replacement Manual". You can find it as a pdf file further down on this page under "Downloads & Information".
The Ferropilot 220S LED search light is just as suitable for boats and yachts as it is for land vehicles.The housing (available in black or white) is made of plastic (ASA), which is UV and salt water resistant (IP 56). The LED module is dust and waterproof (IP 68). The LEDs have an aluminium housing as a heat sink. The lens is made of hardened polycarbonate.The 220S LED search light can be quickly mounted on the base using four screws. The power cable is also fed through the base of the search light.Safety note: The search light is not suitable for vertical or upside-down mounting. This can have an impact on its function and tightness.The headlight can be controlled using either the radio remote control or (optionally) the joystick (both control elements are included in the scope of delivery). The radio remote control and joystick can be rotated 360° horizontally (continuously - without stopping!) and swivelled 135° vertically. When the search light is switched off, it automatically returns to its starting position.The ten high-quality LEDs from Osram provide a light intensity of 460,000 candela (approx. 20 times that of a hand-held distress torch). The range is up to 1,370 metres!The LED search light can be operated with either 12 or 24 volts. The energy consumption is only 50 watts.By using the optional flood light adapter (Article-No. 3307-100), the light can be spread more widely if, for example, obstacles need to be recognised at close range in narrow waters. You will find the adapter further down on this page under "Accessories".Technical dataColour temperature: 5,700 - 6,000 KLight distribution: spot (8° beam angle)12V and 24V (power supply 9 - 36 V)Energy consumption of the integrated motor (max.): 13.5V - 5A; 28V - 3AOperating temperature: -30°C to +70°CDimensions (WxHxD): 18.15cm x 19cm x 16.4cmWeight: 2.1kgCertifications: CE / FCC / R10 (EMV)
Floodlight adapter for the Ferropilot 220S LED searchlight.The adapter turns the focussed searchlight into a floodlight that spreads the light widely. When supplemented in this way, the LED searchlight is ideal for canal trips or for trips in narrow fjords where obstacles need to be recognised at a short distance.It is easy to install by changing the front panel, which is attached with four screws.Colour: blackWeight: 1 kg
Powerful and waterproof searchlight from the 8502 series for installation in the cabin roof.The searchlight can be rotated 360° and tilted 30° using the rod handle. Two H3 halogen lamps in FF reflectors are used as light sources, one for the close range, the second can be switched on separately for the long range. Maximum light range 800 m.Housing, mounting base with ball joint and handle are made of black plastic, the reflector is made of high-gloss vapour-coated aluminium. Pre-wired with 35 cm cable, protection class IP68.The scope of delivery includes 2 halogen lamps (12 Volt=55 W/24 Volt=70 W).
