Art. No.
model
L (mm)
H (mm)
T (mm)
output
consumption
air circulation
Price (unit)
Delivery time
Note list
Buy
4723-025 VIKING AIR4242781400,95-3,0 kW0,1-0,32 l/h56-110 m³/h
€1,999.00*
net: €1,679.83

In stock

The item is in stock ready for shipping. The delivery time is approx. 1 to 3 working days.
Showing 1 to 1 of 1 products

Further development of the proven WALLAS DT diesel hot air heater, produced in Finland.
Laminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise emission, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the harbor.
The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.
Very low power consumption. Can also be started with very low on-board voltage (from 9.6 V). Effective fresh air circulation for ventilation without heating is possible.
Uncomplicated installation of the heaters in the engine room.
Long service life, in corrosion-resistant metal housing, 3-year warranty, worldwide service network.

The heating is controlled via the wired Advanced control panel, which has Bluetooth and WLAN connectivity (wireless system update and control via smartphone app also possible). The separate wireless Bluetooth room thermostat (extremely simple and flexible installation, multiple thermostats possible) can be placed where the temperature is actually to be measured.
Functions: stepless manual control, intelligent processor-controlled thermostat control, two-stage boost function, sun switch (switches off automatically on warm days), child lock, LED backlight.

With built-in fuel pump.
For 12 V on-board voltage, 0.5-2.2 A .
Two air inlets, two hot air outlets D=75mm.

See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, the replacement of old systems is extremely simple.

Scope of delivery: heater, wall bracket with fixing screws, control panel (with 6.0 m connection cable), 4.0 m fuel line with filter, 4.0 m connection cable with 15 A fuse. Material for flue gas, supply and hot air installation is not included.

To assemble the installation material for your heating system, please also use the online support on the manufacturer's website:
WALLASVIKING AIR installation accessories

Description

Further development of the proven WALLAS DT diesel hot air heater, produced in Finland.
Laminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise emission, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the harbor.
The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.
Very low power consumption. Can also be started with very low on-board voltage (from 9.6 V). Effective fresh air circulation for ventilation without heating is possible.
Uncomplicated installation of the heaters in the engine room.
Long service life, in corrosion-resistant metal housing, 3-year warranty, worldwide service network.

The heating is controlled via the wired Advanced control panel, which has Bluetooth and WLAN connectivity (wireless system update and control via smartphone app also possible). The separate wireless Bluetooth room thermostat (extremely simple and flexible installation, multiple thermostats possible) can be placed where the temperature is actually to be measured.
Functions: stepless manual control, intelligent processor-controlled thermostat control, two-stage boost function, sun switch (switches off automatically on warm days), child lock, LED backlight.

With built-in fuel pump.
For 12 V on-board voltage, 0.5-2.2 A .
Two air inlets, two hot air outlets D=75mm.

See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, the replacement of old systems is extremely simple.

Scope of delivery: heater, wall bracket with fixing screws, control panel (with 6.0 m connection cable), 4.0 m fuel line with filter, 4.0 m connection cable with 15 A fuse. Material for flue gas, supply and hot air installation is not included.

To assemble the installation material for your heating system, please also use the online support on the manufacturer's website:
WALLASVIKING AIR installation accessories
