WALLAS SPARTAN TWIN Diesel hot-air heater 4.5kW

Further development of the proven WALLAS DT diesel hot air heater, produced in Finland.Laminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise emission, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the harbor.The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.Very low power consumption. Can also be started with very low on-board voltage (from 9.6 V). Effective fresh air circulation for ventilation without heating is possible.Uncomplicated installation of the heaters in the engine room.Long service life, in corrosion-resistant metal housing, 3-year warranty, worldwide service network. The heating is controlled via the wired Advanced control panel, which has Bluetooth and WLAN connectivity (wireless system update and control via smartphone app also possible). The separate wireless Bluetooth room thermostat (extremely simple and flexible installation, multiple thermostats possible) can be placed where the temperature is actually to be measured.Functions: stepless manual control, intelligent processor-controlled thermostat control, two-stage boost function, sun switch (switches off automatically on warm days), child lock, LED backlight.With built-in fuel pump.For 12 V on-board voltage, 0.5-2.2 A .Two air inlets, two hot air outlets D=75mm.See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, the replacement of old systems is extremely simple.Scope of delivery: heater, wall bracket with fixing screws, control panel (with 6.0 m connection cable), 4.0 m fuel line with filter, 4.0 m connection cable with 15 A fuse. Material for flue gas, supply and hot air installation is not included.To assemble the installation material for your heating system, please also use the online support on the manufacturer's website: WALLASVIKING AIR installation accessories

Further development of the proven WALLAS DT diesel hot-air heater, produced in Finland.Laminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise emission, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the port.The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.Very low power consumption. Effective fresh air circulation for ventilation without heating is possible.Uncomplicated installation of the heaters in the engine room.Long service life, in corrosion-resistant metal housing, 3-year guarantee, worldwide service network. All devices are designed for 12 V on-board voltage.The heater is controlled via an external wired control panel with integrated room thermostat. Functions: stepless manual control, intelligent processor-controlled thermostat control, two-stage boost function, sun switch (switches off automatically on warm days), child lock, LED backlighting.With built-in fuel pump.For 12 V on-board voltage, 0.55-1.0 A .Two air inlets, two hot air outlets - each 75 mm in diameter.See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, the replacement of old systems is extremely simple.Scope of delivery: heater, wall bracket with fixing screws, control panel (with 6.0 m connection cable), 4.0 m fuel line with filter, 4.0 m connection cable with 15 A fuse. Material for exhaust, supply and hot air installation is not included.Heating and on-board voltage can be controlled and monitored with the optional remote control type 4430 via SIM card using an app on a smartphone, tablet or PC.To put together the installation material for your heating system, you can also use the online support on the manufacturer's website:https://www.wallas.fi/accessories/units/22gb/index.php

New development from the Finnish heating specialist WALLAS: The combined air/water heater VIKING COMBI makes it possible to use 10% to 40% of the heating output to heat domestic hot water (with an optional external boiler), to operate external radiators or underfloor heating. Up to 90% of the heating output can be used to heat air.Laminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the port.The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.Very low power consumption. Can also be started with very low on-board voltage (from 9.6 V). Effective fresh air circulation for ventilation without heating is possible.Uncomplicated installation of the heaters in the engine room.Long service life, in corrosion-resistant metal housing, 3-year warranty, worldwide service network. The heating is controlled via the wired Advanced control panel, which has Bluetooth and WLAN connectivity (wireless system update and control via smartphone app also possible). The separate wireless Bluetooth room thermostat (extremely simple and flexible installation, multiple thermostats possible) can be placed where the temperature is actually to be measured.Functions: stepless manual control, intelligent processor-controlled thermostat control, two-stage boost function, sun switch (switches off automatically on warm days), child lock, LED backlight.With built-in fuel pump.For 12 V on-board voltage, 0.55-1.0 A .Two air inlets, one hot air outlet D=75mm, connections for water circuit D 19mm.See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, replacing old systems is extremely easy.Scope of delivery: heater, wall bracket with fixing screws, control panel (with 6.0 m connection cable), 4.0 m fuel line with filter, 4.0 m connection cable with 15 A fuse.Material for flue gas, supply and hot air installation as well as circulation pump for the hot water circuit are not included.

Powerful 12 V diesel heater.The SPARTAN AIR model offers the latest remote control functions on the market for marine heaters, making operation convenient for everyone. The heater's control panel can be accessed remotely via a mobile app. This makes it easy to switch on and operate the heater from home.A wireless sensor monitors the indoor temperature with high accuracy and ensures an even temperature in the boat.SPARTAN AIR has three inlet openings. In comparison, SPARTAN TWIN has two and many other heaters on the market have only one. Multiple inlet hoses ensure better efficiency and fresher air in the interior. Both models in the SPARTAN series are energy-efficient 4.5 kW heaters - a good choice for medium-sized boats up to 12 m/40 ft.Heating output 1.4 - 4.5 kW3 fresh air inlets3 hot air outletsIntegrated fuel pump12 volts, 0.7-4.5 ampsLaminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the harbor.The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.Very low power consumption. Can also be started with very low on-board voltage (from 9.6 V).Effective fresh air circulation for ventilation without heating is possibleUncomplicated installation of the heaters in the engine roomLong service life, in corrosion-resistant metal housing3-year guaranteeWorldwide service networkThe heating is controlled via the wired Advanced control panel, which has Bluetooth and WLAN connectivity (wireless system update and control via smartphone app also possible). The separate wireless Bluetooth room thermostat (extremely simple and flexible installation, multiple thermostats possible) can be placed where the temperature is actually to be measured.Functions:stepless manual controlintelligent processor-controlled thermostat controltwo-stage boost functionSun switch (switches off automatically on warm days)Child safety lockLED backlighting.See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, replacing old systems is very easy.Scope of delivery:(Material for the installation of flue gas, supply air and hot air pipes is not included, as this must be adapted individually for each ship)HeaterWall bracket with fixing screwsControl panel (with 6.0 m connection cable)Wireless Bluetooth room thermostat4.0 m fuel line with fuel filter4.0 m connection cable with 15 A fuse

The most powerful WALLAS diesel heaterAs one of the most powerful models, the WALLAS SPARTAN TWIN offers the most advanced control functions on the market for marine heaters, ensuring maximum comfort and versatility.The heating control panel can be accessed remotely via the WALLAS app. This makes it easy to switch on and operate the heating from anywhere.The wireless sensor monitors the room temperature with high accuracy and ensures even temperature stability and maximum comfort.An important feature of the SPARTAN TWIN, which contributes to the optimal use of its application, are the two fresh air inlets and two hot air outlets. In comparison, the Spartan Air has three inlets and three outlets.Multiple supply air sources ensure better efficiency and fresher air in the interior. Both the SPARTAN TWIN and SPARTAN AIR heaters have a rated output of 4.5 kW and are an excellent choice for boats from 9 to 12 meters (29-40 ft).Heating output 1.4 - 4.5 kW2 fresh air inlets2 hot air outletsIntegrated fuel pump12 volts, 0.7-4.5 ampsLaminar flow burner technology and brushless radial fan ensure high warm air output with minimal noise, even without a silencer. Pleasant operation for the crew and freedom from disturbance for adjacent berths in the harbor.The future-oriented Greenboost burners are suitable for automotive diesel (EN 590) and fuels with a higher proportion of renewable fuels and guarantee low diesel consumption with low-emission combustion.Very low power consumption. Can also be started with very low on-board voltage (from 9.6 V).Effective fresh air circulation for ventilation without heating is possibleUncomplicated installation of the heaters in the engine roomLong service life, in corrosion-resistant metal housing3-year guaranteeWorldwide service networkThe heating is controlled via the wired control panel, which has Bluetooth and WLAN connectivity (wireless system update and control via WALLAS app also possible). The separate wireless Bluetooth room thermostat (extremely simple and flexible installation, multiple thermostats possible) can be placed where the temperature is actually to be measured.Functions:stepless manual controlintelligent processor-controlled thermostat controltwo-stage boost functionSun switch (switches off automatically on warm days)Child safety lockLED backlighting.See table for dimensions. As the dimensions and connections correspond to the proven heaters of the WALLAS DT series, replacing old systems is very easy.Scope of delivery:(Material for the installation of flue gas, supply air and hot air pipes is not included, as this must be adapted individually for each ship)HeaterWall bracket with fixing screwsControl panel (with 6.0 m connection cable)Wireless Bluetooth room thermostat4.0 m fuel line with fuel filter4.0 m connection cable with 15 A fuse
