SKYLOTEC RESC B rescue triangle for transporting people

Basket stretcher according to ISO 13485:2003 made of robust, orange plastic.Thanks to numerous handles all around, the stretcher can be carried well and safely.The patient lies comfortably on a foam padding. He can be secured with three straps. The footrest and adjustable leg lock allow the patient to be lifted vertically, for example up steep slopes.The four-point Bridle (to be ordered optionally) can be attached to four stable eyelets. With this, the stretcher is also suitable for air rescue (lowering by helicopter).

MED / SOLAS approval (see further down on this page under "Downloads & information").Small, bright LED flashing light (at least 0.75 cd) for retrofitting to lifejackets.The compact plastic housing with flat light dome can be easily attached to any lifejacket using the supplied retaining clip with belt slots.The light is automatically triggered by contact with water. However, it can also be switched on and off manually. More than fulfils the IMO/SOLAS regulations: minimum light duration of eight hours. The alkaline battery guarantees a service life of five years.Dimensions of the lamp in the clip: 66 x 36 x 21 mm, weight 50 g. Lamp without clip: 61 x 30 x 21 mm, 40 g.

HAMMAR HR-0500 manual release hook made of stainless steel for attaching the liferaft. The hook can be used alone or in conjunction with a hydrostatic release unit (HRU), such as the HAMMAR H20R. The quick-release hook is inserted into the lashing loop (see video) and allows the webbing strap that secures the island in its holder to be pulled through tightly. In an emergency, the hook can be released quickly by hand so that the life raft can be thrown into the water. To do this, the safety split pin is pulled out, which can be done with one hand even with a heavy lashing load. If the liferaft can no longer be released manually before the ship sinks, the hydrostatic release unit (HRU) takes over. At a water depth of 1.5 - 4 metres, a spring-loaded blade automatically cuts through the lashing of the liferaft, which then slips out of the manual release hook. This allows the raft to float freely. A longer connecting wire to the lashing and the safety pin are available as accessories. Please ask us about them. Technical features Made of Stainless steel Dimensions: 85 x 170 x 102 mm Weight: 205 g Maximum working load: 15 kN

Light isolating thermal blanket, gold / silver shielded foil, to protect from heat or cold. Reflects up to 85% of body heat. Limit the heat loss of accident victims. Prevents from hypothermia.Survival gear for lifeboats and life rafts. Protection against the cold: the patient is wrapped into the blanket, the silver coating is directed towards the body. Dimensions: 1.60 x 2.10 m, packed small 115 x 90 x 10 cm, weight 40 g.CE approved. No SOLAS approval.

Simple inflatable life jacket of the 100N class according to ISO 12402-4, with a manual release.Especially qualified as emergency equipment on ships sailing inland, which are required to carry such life jackets, or as standby equipment on other ships. The floating body comes vacuumized in a robust transparent bag. Very small storage size. Orange colour with reflective stripes and a signal whistle. Life time 10 years (if an annual self-check is carried out on board) . No external service required, if stored under appropriate conditions..

Man-overboard rescue device especially for inflatable boats. The Jasons's Cradle is a very stable personal rescue device that can be used to transport even an injured or unconscious person from the water on board with little effort.The personal rescue system consists of rectangular plastic elements that together form a grid. This is attached to the side of the boat with high-strength carabiners and lowered into the water like a rope ladder.The person in the water can hold on tightly to the elements and, in the best-case scenario, can float up independently (or with support).Alternatively, the Jasons's Cradle FRC Kit can be pulled up by the robust loop (with a line extension if necessary). This forms a tube into which the person in the water either swims independently or is towed into it. In a horizontal lying position, the person is then "rolled" upwards.The Jasons's Cradle is made of high-quality plastic and V4A stainless steel and can be rolled up tightly for storage.Supplied complete with four fastening patches that can be attached to the inflatable boat and a robust stowage bag.For solid fuel (rescue) boats, the Jason's Cradle FRC Kit is available in the above sizes with screw-on eyebolts instead of the adhesive patches. The article number then ends with "H" for hard hull.

The Jasons's Cradle is a very stable personal rescue device that can be used to transport even an injured or unconscious person from the water on board with little effort.The personal rescue system consists of rectangular plastic elements that together form a grid. This is attached to the side of the boat with high-strength carabiners and lowered into the water like a rope ladder.The person in the water can hold on tightly to the elements and, in the best-case scenario, can float up independently (or with support).Alternatively, the Jasons's Cradle with the strong 14 mm diameter rescue ropes can be caught up via a halyard. This forms a tube into which the person in the water either swims independently or is towed into it. In a horizontal lying position, the person is then "rolled" upwards.The Jasons's Cradle is made of high-quality plastics and V4A stainless steel and can be rolled up tightly for storage. Robust panniers are available as accessories for the short lengths (see ´Accessories´) and robust covers for the longer elements. Please ask us about them.In addition to the dimensions listed here, numerous other dimensions are available.There are two further widths to choose from: five elements (= 880 mm) or 6 elements (=1050 mm)The length can be up to 6.87 metres and is then suitable for a freeboard height of up to five metresYou can find a list of the various available dimensions in the table in the second image. Please quote the corresponding product code when enquiring. Thank youIn addition to the standard dimensions, the JASON'S CRADLE personal recovery system can also be customised to your requirements. Please ask us for a quote for your individual production dimensions.

SOLAS approved, small and lightweight night light for lifebuoys.Approved as explosion-proof version (CE 1026) for tankers and gas vessels and other hazardous areas (e.g. offshore platforms). The buoy light emits a bright flashing light (brighter than 2 cd/50 flashes per minute) and is completely maintenance free - no battery replacement. Triggered by a patented switch when removed from the holder. Highest explosion protection classification according to ATE X/IECEx: II1G T4 (for all zones, temperature range below 135°C).Supplied with black plastic holder and 2 m fixing cord.

Ready-made 8 mm-lifeline in various lengths for attaching to the lifebuoy.The line complies with the regulations of the BG Verkehr (formerly See-Berufs-Genossenschaft SeeBG).3-carded, twisted floating line made of PP split, UV-stabilised.Colour: orange/black.

Heavy-duty bracket made of seawater-resistant light metal, rivet construction. The lifebuoy holder is suitable for all lifebuoys with a diameter of 75 cm (INTERNATIONAL type).The bracket is suitable for wall mounting. A 3-piece clamp set for tubes from 15 mm to 22 mm is available for mounting on the railing.Weight: 1.06 kg

Life raft from the brand manufacturer LALIZAS with various approvals, such as EEP (4232/46/00). See also further down on this page under "Downloads & Information".The collective life raft has a rigid polyethylene (PE) shell and is filled with polystyrene foam. These materials guarantee a long service life.The cover has a bright orange signal colour. The all-round safety line is fitted with plastic handles.The life raft is available in three sizes: for four, eight or twelve people.Volume: 80 litres (raft for four people), 151 litres (eight people), 252 litres (twelve people).Weight: 5 kg (raft for 4 people), 11 kg (eight people), 18 kg (twelve people).

Self-raising and self-igniting SOLAS-approved night light for the person-overboard accident. The housing is made of orange-red plastic. The bulb has an E10 socket, 4.8 volts and 0.75 amps.The light is connected to the life ring and automatically activated by a switch. The continuous light has a luminous intensity of 2 candela, the operating time is at least 2 hours.Recommended accessories: 4 alkaline batteries 1.5 volts, type UM1(LR20).Bracket made of plastic or stainless steel.Supplied without batteries and without holder.

The FP throw line is a very practical accessory for attaching a safety line directly to the lifebuoy (with an internal diameter of 38 cm or 45 cm).The bottle-shaped, buoyant container is made of white plastic. It is clamped into the lifebuoy, which requires a certain amount of force. The buoyant braided line (diameter = 5 mm) made of orange PP, breaking load approx. 250 kg, is stowed in the container. It is connected to the ring with the eye at its end.The line is thus protected against weathering and damage. The lifebuoy is ready to be thrown at any time. In an emergency, the line container is removed from the ring, held and the ring thrown. The line runs out in an orderly fashion, making a person-overboard maneuver easier and safer.The throwing line in the container is also ideal for equipping lifebuoys in harbors, at locks or jetties.Available in two sizes.

LED marine emergency light for use on a lifebuoy or MOB lifebuoy to mark your position at dusk / in the dark.The MARINER lifebuoy light with MED approval switches on automatically after being cast overboard by raising the device in the water. The light will also come on in water covered with fuel or oil. The launching height is tested up to 60 m (SOLAS specification is 30 m).High-quality components such as a robust plastic float, a brass battery tube, a switching relay with tilt switch and a special bulb guarantee reliable operation and a long service life. This quality product "Made in Germany" from PyroPol has already proven itself in use worldwide for decades.The MARINER lifebuoy light shines with a light intensity of at least 2 candela.Two types of brackets are available as accessories for mounting on board (see also "Accessories & spare parts").The required 3 x 1.5 volt LR20 DURACELL alkaline mono cells are included in the scope of delivery.

INTERNATIONAL lifebuoy made of orange-red PE hard plastic. The ring is particularly hard-wearing and weather-resistant. It is fitted with two reflective strips in four positions on the front and back of the ring and has an all-round grab line.Labeling with adhesive letters is possible (see "Accessories & spare parts").The lifebuoy has CE and MED approval (certificate under "Downloads") and complies with DIN EN14144.The ring is also available in a heavier (4 kg) version, which can be supplemented with a MOB light-smoke signal (see "Related articles").Technical features:Maximum discharge height: 80 mOuter diameter: 73 cmInner diameter: 44 cmWeight: 2.5 kg

Lifebuoy housing in a closed design with a hinged lid containing a small viewing window.The housing meets the requirements of DIN ISO 18421:2016 "Ships and marine technology - Inland navigation vessels - Housing for lifebuoys".The housing is made of thick-walled PE plastic. The lid is equipped with sturdy hinges and a storm-proof rubber closure. There is a sticker in the middle of the lid with the "Rescue of drowning persons" instructions from the German Social Accident Insurance (DGUV).The lifebuoy case offers space for a lifebuoy with a diameter of 75 cm in accordance with DIN/SOLAS plus a 30 m long throw line.It is supplied without contents (lifebuoy, line) and without fastening material.The housing is designed for wall, post or railing mounting. A suitable post and corresponding mounting sets can be found under"Accessories & spare parts".Technical featuresDimensions (L x W x H): 900 x 900 x 240 mmWeight: 10.6 kgColor: orange

Red lifebuoy wall housing suitable for lifebuoys in all sizes.The housing meets the requirements of DIN ISO 18421:2016 "Ships and marine technology - Inland navigation vessels - Housing for lifebuoys".Closed shape with hinged lid. The box is made of glass fiber reinforced plastic using the hand lay-up method. A strong, spring-loaded lock made of stainless steel is used to prevent unintentional opening in the event of a storm. The hinges are made of plastic.There is enough space in the housing to store a 30 m throwing line in addition to the lifebuoy.The BGF "Rescue of drowning persons" sign is affixed to the center of the lid.Technical featuresDiameter: 880 mmDepth: 160 mmSuitable for wall, post or railing mountingSupplied without fixing material and without lifebuoy

High performance microprismatic tape for maritime applications. Specifically designed for use in harsh environments which includes continuous immersion in sea water and extreme temperatures. Self adhesive with high holding strength.Spare reflective patches for life buoys, life boats etc. Pack with 6 strips of 50 x 100 mm each. Also available loose by the meter or in rolls of 45,7 m (please check "Suitable items"). Approved SOLAS / MED.

High performance microprismatic tape for maritime applications. Specifically designed for use in harsh environments which includes continuous immersion in sea water and extreme temperatures. Self adhesive with high holding strength.Width 5 cm.Comes loose by the meter.Also available in rolls of 45.7 m or as a pack of 6 single strips (please check "Suitable items"). Approved SOLAS / MED, permanently marked with shipswheel logo for immediate compliance identification.

The rescue net is manufactured in Germany and consists of a high-strength webbing reinforced with stainless steel and aluminum tubes in a robust standby case. The net is attached, for example to the railing feet, with 4 straps. After opening with a pull strap, the net falls out and serves as a rescue climbing net or lifting net to lift a hypothermic person as gently and horizontally as possible on board.Pack size: length 100 cm, diameter approx. 12 cm.

Safty instructions from "Berufgenossenschaft Verkehr" (BGV) for saving drowning persons.Available in three versions:- Waterproof panel (30 x 42 cm)- Adhesive label (30 x 42 cm) or round (diameter 25 cm and 37 cm) for life buoy boxes

Children's size 75N! An inexpensive approved life jacket for licensed ships. Approved SOLAS 2010 / MED.Stows easily.Equipped with whistle and reflective stripes. No light supplied.The SOLAS approved emergency light DANIAMANT may be ordered separately.

An inexpensive lifejacket for licensed passenger boats.150N.Approved SOLAS 2010 (MED1050016). Equipped with whistle and reflector stripes. Stows easily. No emergency light supplied. The SOLAS approved emergency light DANIAMANT may be ordered separately.

Solid life jacket of the 100N class, conforming to ISO 12402-4 (former EN395).One size fits all for adults weighting more than 40 kg or children 15-40 kg.Equipped with an emergency whistle, reflective stripes and a 30 mm belly strap.Conforming to the obligation for equipment on board of passenger vessels according to BinSchUO..Colour: orange.
